Technical Specifications
| Measuring Range(um) | 0 to 10000 |
| Working Principle | Magnetic induction |
| Low Resolution | 1 |
| Test Conditions | Minimum radius of curvature (10 mm) The smallest area of the diameter (40 mm) Matrix critical thickness (2 mm) |
| Indication Error(um) | ±(2%H+10) |
| Display | High contrast segment code LCD screen (LED backlight) |
| Statistical Function | The number of measurements, the maximum, the minimum, the average, the standard deviation |
| Calibration Method | Zero-point, one point, two points calibration |
| Operating Temperature | 14 °F to 122 °F (-10 ℃ to +50 ℃) |
| Automatic Shut-down | 3 minutes after no operation automatically shut down |
| Power Supply | Two 1.5V AA batteries, when the battery power is low, there is a low voltage prompt |
| Weight | Containing battery 0.44 lb (200 g) |
| Size | 5.86 in x 2.87 in x 1.26 in (149 mm X 73 mm X 32 mm) |
