Features
- Intuitive touchscreen operations
- Recalling the curve reading cursor function.
- When more channels are needed, the i/o module can be added
- Relay alarm output.
- Provide transmitter DC 24 V isolation distribution
- Through the EMCIII level, ensure the instrument works well in a bad environment.
- Recalling the curve reading cursor function.
- Flexible and convenient file operating system
- The WiFi interface is used to implement online operation
Technical Specifications
| Interface | RS232, USB HOST, USB Device, LAN |
| Usage | Industrial |
| accuracy | ±0.2% F.S |
| channels | 32 channels |
| thermal resistance | Pt100 (three wire system) |
| thermocouples | K, S, R, B, N, E, J, T |
| Current output | 4 mA to 20 mA, 0 mA to 10 mA, 0 mA to 20 mA optional |
| Voltage output | 0 V to 5 V, 1 V to 5 V optional |
| Single package size | 13 in x 11 in x 12.6 in (330 mm x 280 mm x 320 mm) |
| Single gross weight | 16.53 lb (7.500 kg) |
