Features
- Up to 18 channels of universal input
- UP to 4 Alarm Output Relays
- With 150mA Power distribution Output
- Communication type: RS485, Modbus RTU
- With a USB data transfer interact
Technical Specifications
| Display | 3.5 in TFT true color LCD screen |
| Thickness Of Mounted Panel | 1.5 mm to 6.0 mm |
| Power Supply | 176 VACS to 264 VAC ,47 Hz to 63 Hz |
| Internal Storage | 48 M bytes |
| The Maximum Power Consumption | 20 VA |
| Relative Humidity | 5 % to 95% RH |
| Operating Temperature | 32 °F to 122 °F (0 °C to 50 °C) |
| Dimension | 3.77 in x 3.77 in x 3.93 in (96 mm × 96 mm × 100 mm) |
| Weight | 0.81 Oz (0.37 kg) |
