Features
- Two detection methods: standard and simple depth measurement
- Standard ultrasonic transducer bracket, precise and adjustable; free from scene marking out, which can greatly improve the detection efficiency
- Touch screen makes the operation simple and quick
- The whole process of testing is prompted by voice and text
- Friendly human-computer interactive interface
- Various built-in helpful files and demo videos facilitate the users to conduct skilled instrument operation
- 4GB large-capacity SD card can store more than 100,000 data
- Powered by lithium batteries
Technical Specifications
| Hardware Platform | Embedded ARM9 Hardware Platform, WinCe5.0 Operating System, and True Color TFT Touch Screen |
| Crack Depth Test Range | 10 mm to 500 mm |
| Accuracy | ≤ ± 5 % |
| Power Supply | Rechargeable Lithium Battery |
| Working Humidity | ≤ 90 % RH |
| Working Time | ≥ 28 Hours |
| Working Temperature | 14 °F to 122 °F (- 10 °C to 50 °C) |
