| System |
GPS + BEIDOU + GLONASS |
| Chipset |
AT6558R |
| Receiver |
32 Channel |
| Resolution |
1920 pixels x 1080 pixels |
| Cold start |
≤32 s |
| Connection |
3G/4G SIM Card, 2G SIM Card |
| Hot start |
≤1 s |
| Cold start capture sensitivity |
148 dBm |
| Tracking sensitivity |
165 dBm |
| Accuracy |
<98.42 in (2500 mm) CEP50 |
| Material |
Engineering plastic |
| GPS Module |
AT6558R |
| GSM module |
Quectel M25, EC200 series or EC25 series |
| Working temperature |
-4 oF to 176 oF (-20 °C to 80 °C) |
| Store temperature |
-40 oF to 176 oF (-40 °C to 80 °C) |
| Humidity |
5% RH to 99% RH |
| Built-in battery capacity |
Rechargeable battery 10400 mAh |
| Average working current |
<90 mA |
| Average current standby |
<100 uA |
| Working hour |
2G device (10400 mAh) continuous full load operation for 100 hours3G/4G device (10400 mAh) in normal working mode for 70 hours |
| Waterproof |
IP 67 |
| Transmission mode |
Support TCP(GPRS) or SMS (short message) |
| Charging specification |
DC 5 V, 2 A, 5521 interface |
| Motion sensor |
3D acceleration sensor |
| Memory |
2 MB |
| Antenna |
GSM/GPS default built-in antenna |
| Lock hook |
Stainless steel, tensile resistance 440.92 lb (200,000 g) |
| LED |
4 indicators, (Communication, Location, Low power, Charge） |
| SIM |
Double card single standby, Micro SIM card |
| Size |
7.67 in x 4.48 in x 1.45 in (195 mm x 114 mm x 37 mm) |
| Weight |
1.83 lb (833 g) Include main unit and Hard lock hock soft rope |
