Overview
Hospitality Enviro Tech concrete gauge crack detector is used for testing the crack depth and width. It is one professional crack measurement in one comprehensive test instrument, mainly used for crack detection of bridges, tunnels, walls, concrete pavement.
Features
- Large-screen display
- 5 in (127 mm) color LCD display
- Resolution of 640 pixels x 480 pixels
- The colorful camera has the direction mark
- The tester is equipped with a dedicated scale
- Easy data transfer
- Powerful professional windows data analysis processing software
Technical Specifications
| Crack Width Test Range | 0 in to 0.3 in (0 mm to 8 mm) |
| Width Test Accuracy | 0.0004 in (0.01mm) |
| Crack Depth Test Range | =< 25.6 in (=< 650 mm) |
| Crack Depth Accuracy | =<10% |
| Data Storage Capacity | can store more than 100,000 cracks measured point data and image |
| Power | Rechargeable Li battery |
| Operating Temperature | 14 °F to 122 °F (-10 °C to 50 °C) |
| Main Host Dimension | 8.2 in x 6.6 in x 3.3 in (208 mm x 168 mm x 85 mm) |
