Overview
Hospitality Enviro Tech concrete deformed steel bar detector is used for both function test like rebar test and rust test. It can identify rebar location, direction and distribution.
Features
- Professional data processing software
- It has charging port and USB Port
- It has also rebar sensor
- Detector has both double – electrode and single- electrode
Technical Specification
| Applicable range | 0.23 in to 1.96 in (6 mm to 50 mm) |
| Protective layer thickness range 1000 mV (mm) | First range 0.11 in to 3.85 in (6 mm to 98 mm) |
| Maximum allowed error for protective layer, ± 0.03 in (1 mm) | 0.11 in to 3.85 in (3 mm to 98 mm) |
| Maximum allowed error for protective layer, ± 0.03 in (2 mm) | 0.23 in to 2.20 in (6 mm to 56 mm) |
| Maximum allowed error for protective layer, ± 0.03 in (4 mm) | 2.24 in to 2.71 in (57 mm to 69 mm) |
| Protective layer thickness range 1000 mV (mm) | Second range 0.11 in to 7.71 in (3 mm to 196 mm) |
| Maximum allowed error for protective layer, ± 0.03 in (1 mm) | 0.11 in to 3.11 in (3 mm to 79 mm) |
| Maximum allowed error for protective layer, ± 0.03 in (2 mm) | 3.14 in to 4.68 in (80 mm to 119 mm) |
| Maximum allowed error for protective layer, ± 0.03 in (4 mm) | 4.72 in to 7.71 in (120 mm to 196 mm) |
| Protective layer thickness range 1000 mV (mm), Corrosion detection method | Measuring range accuracy |
| Protective layer thickness range 1000 mV (mm), Single electrode | ± 1000 mV ± 1 mV |
| Protective layer thickness range 1000 mV (mm), Double electrode | 0 mV to 1000 mV± 1 mV |
| Maximum allowed error for protective layer, Tested points Interval X | |
| Maximum allowed error for protective layer, Single electrode | 0.00 in to 3.93 in (0 mm to 100 mm) adjustable |
| Maximum allowed error for protective layer, Double electrode | 20 fixed |
| Maximum allowed error for protective layer, Single electrode | 0 to 100 adjustable |
| Maximum allowed error for protective layer, Single electrode | Built-in chargeable lithium battery |
| Maximum allowed error for protective layer, Double electrode | 0 to 100 adjustable |
| Maximum allowed error for protective layer, Double electrode | Built-in chargeable lithium battery |
