Overview
Hospitality Enviro Tech Concrete Crack Monitoring Detector is set for automatic measurement of crack width and crack depth on structural surface, automatic interpretation, and storage of data.
Features
- Integrated design. Small size.
- Original wireless camera probe, quick shot button easy to operate; The main machine adopts Windows tablet, Chinese full touch operation.
- Intelligent interpretation of oblique fractures, without vertical; The image can be zoomed in and out, and the scale displayed on the interface can be interpreted manually.
- No marking of sounding support, saving time and effort; Tablet and TF card storage, super-large capacity without limit, copy data convenient, fast.
- The data analysis and report form are provided in the host computer, which can be owned without transferring to the upper computer
Technical Specifications
| MCU (Main Control Unit) | 8InchesTablet PC Windows operating system 32G storage |
| Magnification Times | Digital 60 times |
| Test Range and Accuracy | 0 to 10 mm; 0.01 mm |
| Measurement Accuracy | 5 mm or 2% to 10% of actual depth |
| Work Environment | 50 °F to 104 °F (10 ºC to +40 ºC <90%RH) |
| Package Size | 16.5 in × 5.52 in×13.2 in (420 mm x 140 mm x 335 mm) |
| Testing Range | 0.2 in to 19.6 in (5 mm to 500 mm) |
