Overview
Hospitality Enviro Tech combustible gas detector is a new-generation product for detection of gas leak. Due to its imported sensor which guarantees its high sensitivity, great stability, quick response, smooth operation, and large successive range, it is capable of accurate detection of the leak points and annual leakage rage of Breaker and GIS in both quantitative and qualitative measures. This device is very suitable for the power supply department for MP 30 High-precision, the installation and testing division and experimental institute of power supply. It can also serve as a supporting device for electrical devices and export products by high pressure switch manufacturers while improve the whole level of the product.
Key Features
- Small size, low weight, portable handheld serpentine sensor
- High sensitivity: the device can locate any leakage
- Wide detection range: the device can detect the leakage amount
- High accuracy: based on advanced method of calibration
- Visualized display and sound & light alarm
- Quick response and short recovery time
- Rechargeable Ni-MH Battery and continuous working time of 5 hours
Technical Specifications
| Minimum Detection value | 100 ppm |
| Detection Range | 100 ppm to 2000 ppm |
| Response Time | <5 second |
| Recovery Time | <5 seconds |
| Display Value Error | <±10% |
| Repetitiveness | ≤5% |
| Maximum Motionless Sensor Sensitivity | 0 lb (3 g)/year |
| Indication Methods | LCD display and multi-frequency sound alarm |
| Length of Probe Wire | The portable and snaked-shape detector can extend to 39.3 in (1000 mm) length |
| Continuous Working Time | 24 hours |
| Device Battery | Rechargeable electricity lithium battery, AC/DC |
| Environmental Requirements | temperature: 23 °F to 122 °F (-5 °C to 50 °C) Relative Humidity (RH): ≤85% |
| Size | 9 in x 5.1 in x 1.8 in (230 mm × 130 mm x 46 mm) |
| Weight | 4.4 lb (2 kg) |
