Overview
Hospitality Enviro Tech circuit parameter resistance tester adopts the new technology of the power supply which can continuously output large current for a long time. It overcomes the defect of impulse instantaneous current of the power supply and can effectively break through the oxidation film of switch contact and get good results under the condition of serious interference. The last bit data of LCD can be stable at ± 1 word/ the scope of stable reading, good repeatability. It has a long service life. It adopts high precision resistance which effectively eliminates the influence of the environment temperature on the measurement results. Meanwhile, the use of military connectors enhances the anti-vibration performance.
Technical Specifications
| Measuring range | 1 μΩ to 1999 μΩ |
| Resolution | 1 μΩ |
| Test current | DC 50 A, 100 A, 150 A, 200 A Four speed fixed output |
| Accuracy | 0.5 % ± 1 d |
| Way to work | The connection |
| Display | Three and a half LCD |
| Power supply | AC 220 V ± 10 % 50 Hz |
| Working temperature | 14 °F to 104 °F (-10 ℃ to 40 ℃) |
| Working humidity | ≤ 80 % RH |
| Dimension | 14.5 in x 12.5 in x 10.2 in (370 mm × 320 mm x 260 mm |
| Weight | 21.1 lb (9.6 kg) (excluding attachments) |
