Overview
Hospitality Enviro Tech Chlorine Ion Diffusion Coefficient Tester is a high-precision measurement and control instrument consisting of a microcontroller as the core and a large-scale integrated circuit as a peripheral component. The software and hardware use a variety of anti-jamming technologies, using FLASH to store the working data of the site, with stop and power-down data not lost.
Features
- Automated, user-friendly software control
- Real-time display with customizable views
- Timed printing with comprehensive information
- Restart function with clearable run time
- Multi-layer protection against damage
- RS232 communication for data collection
- Save data via micro printer or computer
Technical Specification
| Relative humidity | ≤75%, no corrosive gas occasion |
| Output voltage accuracy | ±0.05 V |
| Output current accuracy | ±0.05 mA |
| Temperature input signal | DS18B20 single bus temperature sensor |
| Output voltage | 0 V to 70 V |
| Output current range | 0 mA to 300 mA |
| Power supply voltage | AC 220 V ±10% / 50 Hz |
| Power consumption | ≤20 W |
| Ambient temperature | 32 °F to 122 °F (0 °C to 50 °C) |
| Temperature display accuracy | ±0.9 °F (±0.5 °C) |
| Temperature display range | 32 °F to 257 °F (0 °C to 125.0 °C) |
