Features
- Modbus RS-485 for seamless system integration convenience
- Programmable auto-cleaning wiper enhances operational efficiency
- Chemical-free operation with direct UV254 spectral absorption measurement
- Reliable UVC LED technology ensures longevity and instant stability
- Measures SAC, COD, TOC, and BOD accurately
- Advanced turbidity compensation algorithm enhances measurement precision
Technical specification
| Interface | Support RS-485, MODBUS protocols |
| COD Range | 0.75 mg /L to 370 mg/L equiv.KHP |
| COD Accuracy | <5% equiv.KHP |
| COD Resolution | 0.01 mg/L equiv.KHP |
| TOC Range | 0.3 mg/L to 150 mg/L equiv.KHP |
| TOC Accuracy | <5% equiv.KHP |
| TOC Resolution | 0.1 mg/L equiv.KHP |
| Tur Range | 0NTU to 300 NTU |
| Tur Accuracy | <3% or 0.2 NTU |
| Tur Resolution | 0.1 NTU |
| Temperature Range | 41 °F to 113 °F (5 °C to 45 °C) |
| Housing IP Rating | IP 68 |
| Maximum pressure | 1 bar |
| User Calibration | one or two points |
| Power Requirements | DC 12 V ±5%, current<50 mA (without wiper) |
| Sensor OD | 1.97 in (50 mm) |
| Sensor Length | 8.42 in (214 mm) |
| Specification | 1.97 in x 8.42 in Φ (50 mm x 214 mm) |
| Cable Length | 32.80 feet (10 meters), (default) |
