Overview
Hospitality Enviro Tech Chloride Ion Content Tester is an important factor in inducing rebar corrosion. To avoid premature corrosion of rebar, the chloride ion content in concrete raw materials is strictly controlled. When selecting and mixing sand, aggregate, cement, admixture, mixing water and other concrete raw materials, the chloride ion content must be tested to fundamentally avoid bringing excessive chloride ions into the concrete. The chloride ion rapid measuring instrument produced by our company is the laboratory electrochemical analysis instrument for measuring the concentration of chloride ions in fresh concrete. The chloride ion selective electrode is the indicator electrode, supplemented by the appropriate reference electrode, which is inserted into the solution to be tested to form an electrochemical system for measurement.
Features
- Laboratory for corrosion prevention in materials like concrete, gravel, and cement
- Utilizes ion-selective electrode (ISE) method
- an electrochemical sensor with a sensitive membrane
- Converting ion activity into a potential signal
- Outputs molar concentration and mass percentage directly
- Includes built-in temperature compensation program for accurate results
Technical Specification
| Measurement range of chloride ion concentration | 1 mol/L or 5 mol/L x 10 mol/L to 5 mol/L |
| PH range | 4 pH or 10 pH |
| Temperature range | 32 °F or 104°F (0 ℃ or 40 ℃) |
| Response time | ≤2min |
| input power supply | DC 5 V or 500 mA |
| recommended use range: | 50 °F or 86 °F (10 ℃ or 30 ℃) |
