Technical Specifications
| Gas detected | Combustible gas, toxic gas |
| Detection range | (0 to 100%)LEL |
| Resolution ratio | 1% LEL |
| Measurement error | Full Scale ±3%LEL |
| Status indication | LCD |
| Sampling mode | Natural diffusion |
| Response time | T90 s ＜15 s |
| Power | DC24V ±10% |
| Output signal | 4 mA to 20 mA or RS485 |
| Explosion proof grade | Exd ⅡC T6 Gb |
| Ingress protection | IP66 |
| Weight | 7.71 Ib (≤ 0.35 kg) |
| Size | 5.55 in x 7.00 in x 4.92 in (141 mm × 178 mm × 125 mm) |
