Overview
Hospitality Enviro Tech benchtop turbidity meter with the total suspended solids measurement mode, 2 to 7 points calibration, selectable 4 turbidity units. The meter is suitable for laboratory use.
Features
- Equipped with a 4.5 inches TFT display
- 2 to 7 points push-button calibration
- Selectable 4 turbidity units
- Accurate measurement of the total suspended solids
- Auto-Read feature senses and locks the stable reading
- Password protection prevents
- Setup menu allows setting the 9 parameters mode, resolution, etc
- Expanded memory stores and recalls up to 200 data sets
- Stored readings can be transferred into the computer
- Reset feature automatically resumes all settings
Technical Specifications
| Measurement Method | ISO 7027 nephelometric method (90° scattered light) |
| Range | 0 NTU to 2000 NTU, 0 EBC to 500 EBC, 0 ASBC to 9999 ASBC |
| Accuracy | ±2% (0 NTU to 500 NTU), ±3% (501 NTU to 2000 NTU) |
| Resolution | 0.01 (0 NTU to 100 NTU), 0.1 (100 NTU to 999 NTU), 1 (999 NTU to 2000 NTU) |
| Calibration Points | 2 to 7 points (0.02, 10, 200, 500, 1000, 1500, 2000 NTU) |
| Range | Depending on the TSS conversion factor |
| Accuracy | 3% of reading |
| Resolution | 0.1, 1 |
| Light Source | Infrared-emitting diode, 850 nm wavelength |
| Detector | Silicon photodiode |
| Stray Light | < 0.02 NTU |
| Suitable Vials | Round cuvettes, 2.36 in x 0.98 in (60 mm × 25 mm) |
| Power Off | Manual or Automatic (2 hours after last key pressed) |
| Reset Function | Yes |
| Memory | Stores up to 200 data sets |
| Output | USB communication interface |
| Display | 4.5 in TFT LCD |
| Power | DC12V, using AC adapter, 220 VAC/50 Hz |
| Dimensions | 9.84 in x 6.96 in x 3.77 in (250 mm × 177 mm × 96 mm) |
| Weight | 2.64 lb (1.2 kg) |
