Features
- Colour High contrast LCD touchscreen
- Intelligent operation system
- Multi-reading feature allows auto-read
- Automatic/Manual temperature ensures accurate results
- Data Storage 1000 sets for each parameter
- Data analysis feature helps review, compare and recalculate results
- Support for USB or RS-232 communication
- Reset feature automatically resumes all settings
- IP54 waterproof
- 1-6 points calibration with Standard Recognition
- Selectable pH buffer groups, including NIST, DIN, GB
- Support for pH standard group customization
- Automatic electrode diagnosis with pH slope and offset display
Technical Specifications
| Range | -2.000 pH to 20.000 pH |
| Resolution | 0.1 pH, 0.01 pH, 0.001 pH |
| Accuracy | ±0.002 pH |
| Calibration Points | Up to 6 |
| Standard Customization | Yes |
| Calibration Reminder | Yes |
| Standard Recognition | NIST, GB, DIN buffers |
| Slope Limit | Yes |
| Range mV/ORP | -2000.00 mV to 2000.00 mV |
| Resolution mV/ORP | 0.1 mV, 0.01 mV |
| Accuracy mV/ORP | ±0.03% FS |
| Unit Temperature | °C |
| Resolution Temperature | 0.1 |
| Accuracy Temperature | ±0.1 |
| Reading Mode Measurement | Auto Read (Fast, Medium, Slow), Timed, Continuous |
| Reading Prompts Measurement | Reading, Stable, Locked |
| Temp. Compensation | ATC, MTC |
| Data Storage | 1000 Groups |
| GLP Features | Yes |
| Log Management | Yes |
| Inputs pH Electrode | BNC (Q9) |
| Inputs Temp. Probe | 6 pin Mini DIN |
| Outputs USB, RS 232 | USB 2.0 flash memory device, printer, PC |
| Backlight | Yes |
| Auto Shutdown | 1 min to 60 min, off |
| IP Rating | IP54 |
| Date and Time | Yes |
| Power | AC Adapter, 100 V to 240 V AC input, DC 24 V output |
| Range Temperature | 23 °F to 266 °F (-5 °C to 130 °C) |
| Dimensions | 11.02 in × 11.02 in × 5.11 in (280 mm × 280 mm × 130 mm) |
| Weight | 5.51 lb (0.25 kg) |
