Overview
Hospitality Enviro Tech integrated benchtop fiber optic video microscopes, more high-definition, smaller size, more flexible mode of operation, easy to extend the features. It is being recognized and accepted by more and more customers. A dedicated for the inspection of both 2.5mm connectors and 1.25mm connectors, which is equipped with a PC and APC both in one patented fixture, means if you do the PC and APC fiber end-face inspection with a PC/APC both in one fixture, you will no need to replace the fixture, easy to adjust, greatly help end customers save the cost, To improve the inspect efficiency.
Technical Specifications
| Monitor & Scale | 8.0 in TFT or 4:3 |
| Display Magnification and Image size | 400 times or 200 times |
| Effective Pixels | 1024 x 768 |
| Focusing Mode | Manual |
| Operating Voltage/Current | 12 VDC 1000 mA |
| Function | Fibre connector’s end-face inspection |
| Power supply | 12 VDC 1000 mA |
| Operating Temperature | 14 ℉to 140 ℉ (-10 ℃ to 60 ℃) |
| Product Dimension | 10.39 in × 11.06 in × 8.11 in (264 mm x 281 mm x 206 mm) |
| Weight | 3.85 lb (1.75 kg) |
