Technical Specifications
| Class I Test | • Protective conductor resistance (Test current 200mA DC nominal) • Insulation resistance test (250 V or 500 V) • Leakage current test (100 V to 253 V or 50 Hz) • Load current test (100 V to 253 V or 50 Hz) |
| Class II Test | • Insulation resistance test (250 V or 500 V) • Leakage current test (100 V to 253 V or 50 Hz) • Load current test (100 V to 253 V or 50 Hz) |
| Extension Lead Test | • Protective conductor resistance (Test current 200 mA DC nominal) • Insulation resistance test (between Line or Neutral-Earth short, Line or Neutral) • Leakage current test (100 V to 253 V or 50 Hz) • Polarity test |
| RCD Test | RCD test (10 mA or 30 mA) |
| Display Range | 30 V to 270 V |
| Accuracy | ±5 V |
| Measuring Range | 0.00 Ω to 20.00 Ω |
| Open Circuit Voltage | 5 V±0.4 V DC |
| Measuring Current | 200 mA DC (nominal value) |
| Accuracy | ±3% rdg ±5 dgt |
| Rated Voltage | 250 V |
| Measuring Range | 0.00 MΩ to 20.00 MΩ |
| No-load Voltage | 250 V DC +20%, 0% |
| Short Circuit Current | 1.5 mA DC or less |
| Accuracy | ±2% rdg ±3 dgt |
| Rated Voltage | 230 V -15% – +10% or 50 Hz |
| Rated Current | 10 mA or 30 mA |
| Function | × 1 |
| Test Duration | 0.0 ms to 500.0 ms |
| Operating Time Accuracy | ±2 ms(<=40 ms), ±8 ms(>40 ms) |
