Electrical performance Universal antenna for UHF-band RFID
Applications with ultra wide frequency, high gain, low standing wave
Low axis ratio, high front to back ratio and so on.
Mechanical properties are beautiful and compact, easy to install.
Main uses and scope of application
Is a high performance 9dbic circular polarized antenna,
Which can be easily used in UHF band RFID applications
Such as file cabinets, smart containers, tool cabinets,
Warehousing logistics, retail, etc.
Technical Specifications
Frequency Range
860 Mhz To 940 MHz
Impedance
50 Ω
Gain
9 DBi
Polarization
Circular Polarization
Beam Width
Horizontal 65° Vertical 65°
Axial Ratio
≤3 DB
VSWR
≤1.3
Max. Power
50 W
Lightning Protection
Direct Ground
Connector
SMA Female
Reflector Material
ABS
Connector Position
Lateral Extraction
Radome Color
White
Dimension
9.65 In x 10.67 In x 1.10 In (245 Mm x 271 Mm x 28 Mm)
Antenna Weight
1.32 Lbs (0.6 kg)
Operating Temperature
−40 °F To 140 °F (-40°C To 60°C)
