Technical Specifications
| Nominal Voltage | 220 VAC to 230 VAC ± 5% |
| Surge Power | 2 x rated power for 5 seconds |
| Frequency | 50 Hz or 60 Hz |
| WaveForm | Pure Sine Wave |
| Transfer Time | 10ms typical (UPS), 20ms typical (Appliances) |
| Peak Efficiency (PV To INV) | 98 % |
| Peak Efficiency (Batt To PV) | 94 % |
| Battery Voltage | 48 VDC |
| Cold Start Voltage | 46 VDC |
| Low DC Cut-Off Voltage | 44 VDC |
| Maximum Solar Input Current | 27 A |
| Maximum Solar Charge Current | 120 A |
| Maximum AC Charge Current | 80 A |
| Maximum Charge Current | 120 A |
| Size | 17.2 in x 11.6 in x 4.13 in (43.8 cm x 29.5 cm x 10.5 cm) |
| Net Weight | 19.18 lbs (8.7 kg) |
