Features
- High effciency pure sine wave inverter(PF=1);Wide PV input range (120V dc -500V dc) 100A MPPT SCC;Intelligent 3stage 100A AC battery charger.
- Surges to 2X continuous power for 5 seconds for motor loads.
- Intelligent functionality enables utility and solar input prioritization.
- Wide ulility input range (90Vac _280Vac) for unreliable grid even in the most challenging environments.
- Field serviceable with replacement boards and spare parts.
- Monitor, troubleshoot, or communication with USB/RS 232.
- System configures quickly into compact, wall-mounted system.
Technical Specifications
| Rated Power | 5000 VA 5000 W |
| Ac Voltage Regulation (Batt. Mode) | 230 VAC ± 5 % |
| Surge Power | 10000 VA |
| Efficiency (Peak) | 90 % to 93 % |
| Transfer Time | 15 minutes (For Personal Computers) 20 minutes (For Home Appliances) |
| Waveform | Pure sine wave |
| Battery Voltage | 48 VDC |
| Floating Charge Voltage | 54 VDC |
| Overcharge Protection | 63 VDC |
| Dimension | 4.5 in x 11.8 in x 15.7 in (11.5 cm x 30 cm x 40 cm) |
| Net Weight | 24.25 lbs (11 kg) |
