Features
- LCD display screen
- Calibration function automatically recognizes the standard solutions
- Settable parameters, including cell constant, temperature compensation coefficient
- Automatic/Manual temperature compensation ensures accurate results
- Data capacity of up to 250 sets for each parameter
- Data can be transferred to PC or printer by RS-232 communication interfaces
- Auto-power off feature effectively extends the battery usage time
- IP 65 waterproof
Technical specifications
| Parameters | Conductivity, TDS, Salinity, Temp. | |
| Range | Conductivity | 0.000 μS/cm to 199.9 mS/cm |
| TDS | 0.000 mg/L to 19.99 g/L | |
| Salinity | 0.00% to 8.00% | |
| Temperature | 32.0 °F to 104.0 °F (0.0 ℃ to 40.0 ℃) | |
| Resolution | Conductivity | 0.001 μS/cm |
| TDS | 0.00 1mg/L | |
| Salinity | 0.01% | |
| Temperature | 32.18 °F (0.1 ℃) | |
| Accuracy | Conductivity | ±1.0% (FS) |
| TDS | ±1.0% (FS) | |
| Salinity | ±0.20% | |
| Temperature | ±0.54 °F (±0.3 ℃) | |
| Calibration | Up to 5 points | |
| Cell constant(K) | Select from K = 0.01,0.1,1.0 or 10 | |
| Temp. Compensation | Manual/Automatic 32.00 °F to 104.00 °F (0.00 ℃ to 40.0 ℃) | |
| Power Supply | AA battery × 4 | |
| Standard Configuration | Conductivity Electrode: DJS-1CF (Platinum black)ATC Probe: T-818-B-6F
Electrode Holder |
|
| Carrying case | ||
| Optional Accessories | Standard solution | |
| K=0.01,1.0(bright).0.1 or 10 conductive probe | ||
| Overall Dimension | 8.27 in x 3.38 in x 1.97 in (210 mm × 86 mm × 50 mm) | |
