Features
- Customized multi-parameter analyzer
- Different measurement range
- Accurate and stable data
- Communication and control
- Various installation methods
Technical Specifications
| Detection Object | PH, ORP, Temp, conductivity, dissolved oxygen, turbidity, chlorine |
| PH Sensor | Principle: glass electrode method Range: 0 pH to 14 pH, Accuracy: 0.01 pH |
| Conductivity Sensor | Principle: 2-electrode or 4-electrode Range: 0 mS/cm to 10 mS/cm automatic switching Accuracy: 1 % of the measuring range |
| Dissolved Oxygen Sensor | Principle: fluorescence method Range: 0 mg/ L to 20 mg/L Accuracy: ± 0.1 mg/L |
| Turbidity Sensor | Principle: infrared 850 nm 90° scattered light method Range: 0 NTU to 1000 NTU, 0 NTU to 4000 NTU Accuracy: < ± 1 % of the measuring range |
| Configuration Information | Power failure protection, indefinite retention of parameters |
| TEMP Sensor Input | PT1000 or NTC10K |
| Temperature Compensation | Automatic or manual |
| Relay Output | A wash relay, max. load 3 A or 250 VACS |
| Communication Method | RS485 interface |
| Communication Protocol | Modbus RTU, support JSON text |
| Time or Data Logging | Accurate to the second, record 7800 historical data, support data download Recording interval can be set between 1 and 999 minutes |
| Maintain Records | Last 100 times |
| Display | 3.2inch 128 mm x 64 mm LCD screen |
| Language | English |
| Protection Grade | IP66 |
| Material | Enhanced ABS |
| Mounting | Wall mounting, pipe clamp, panel mounting (open hole size 138 mm x 138 mm) |
| Power Supply | AC: 100 V to 240 V, 50 Hz to 60 Hz; DC: 18 V to 36 V |
| Power Consumption | < 24 W |
| Operating Temperature | 32 °F to 140 °F (0 ℃ to 60 ℃) RH < 95 % |
| Storage Temperature | -4 °F to 158 °F (-20 ℃ to 70 ℃) RH < 55 % |
| Dimensions | 5.6 in x 5.6 in 4.7 in (144 mm x 144 mm x 120 mm) |
| Weight | 3.5 lb (1.6 kg) |
