Features
- Sea water or high salinity water or various water supply industrial water treatment
- Signal output RS 485 (Modbus RTU protocol) 4 mA to 20 mA current output
- Convenient connection to third-party devices such as PLCs, DCS, industrial control
- General controllers, paperless recording instruments, or touch screens
- Immersion installation with 3 or 4 NPT for easy installation in pipelines and tanks
- IP 68 protection level
Technical Specifications
| Measuring Principle | Induction electrode method |
| Output | RS 485 (Modbus RTU), 4 mA to 20 mA |
| Shell Material | 316 L |
| Installation Method | Input type installation 3 NPT or 4 NPT |
| Consumption | 0.2 W, 12 V |
| Power Supply | 12 VDC to 24 VDC |
| Protection Class | IP 68 |
| Accuracy | ± 1.5 % 32.54 °F (± 0.3 ℃) |
| Working Conditions | 32 °F to 140 °F (0 ℃ to 60 ℃) ≤ 0.6 MPa |
| Storage Temperature | 23 °F to -85°F (-5 ℃ – 65 ℃) |
