Technical Specifications
| Display | 7-inch capacitive touch screen |
| Measurement Range | -2 pH to 19.99 pH |
| Resolution | 0.1 pH / 0.01pH |
| Accuracy | ±0.02 pH |
| Stability | ±0.01 pH / 3h |
| MV Range | -1999.9 mV to1999.9 mV |
| MV Resolution | 1 mV |
| Calibration | 1, 2, 3 points |
| Conductivity Measuring Range | Conductivity: 0 μS/cm to 20 μS/cm, 20 μS/cm to 200 μS/cm 200 μS/cm to 2000 μS/cm, 0 mS/cm to 20 mS/cm, 20 mS/cm to 200 mS/cm, 200 mS/cm to mS/cm(K=10) Resistivity: 0 MΩ/cm to 100 MΩ/cmTDS: 0 g/L to 100 g/L Salinity: 0 ppt to 100 ppt |
| Resolution | 0.01 μS/cm or 0.1 μS/cm or 1 μS/cm, 0.01 mS/cm or 0.1 mS/cm or 1 mS/cm |
| Electrode Constant | 0.1/1/10 cm-1 |
| Data Storage | 300 sets |
| Power Requirements | DC 12 V/1 A (with power adaptor) |
| Communication Interface | Bluetooth, USB |
| Ambient Humidity | ≤85% |
| IP Rating | IP 54 |
| Customized Support | OEM, ODM |
| Application | Water Treatment Industry |
| EC Calibration | 1 point |
| Temperature Range | 14 °F to 50 °F (-10 ℃ to 10 ℃) |
| Temperature Compensation | 32 °F to 212 °F (0 ℃ to 100 ℃) |
| Ambient Temperature | 41 °F to 95 °F (5 ℃ to 35 ℃) |
| Dimensions | 9.44 in x 6.69 in x 2.75 in (240 mm × 170 mm × 70 mm) |
| Weight | 1.32 lb. (600 g) |
