Features
- High resolution LCD display, 5.7 in (144 mm)
- Multi-reading feature allows auto-reading, timed-reading and continuous-read
- Automatic/Manual temperature compensation ensures accurate results
- Auto-hold features senses and locks the measurement endpoint
- Data Storage 500 sets (GLP-compliant)
- Support for USB or RS-232 communication
- The reset feature automatically resumes all settings back to factory default options
- IP54 waterproof
- 1-5 points calibration with Standard Recognition
- Selectable pH buffer groups, including NIST, DIN, GB, USA
- Automatic electrode diagnosis with pH slope and offset display
Technical Specification
| pH Range | -2.00 pH to 20.00 pH |
| pH Resolution | 0.1 pH, 0.01 pH |
| pH Accuracy | ± 0.01 pH |
| pH Calibration Points | Up to 5 points |
| pH Standard Customization | Yes |
| pH Standard Recognition | NIST, GB, USA and DIN buffers |
| mV Range | -2000.0 mV to 2000.0 mV |
| mV Resolution | 0.1 mV |
| mV Accuracy | ± 0.3 mV or ± 0.1 % |
| Measurement Reading Mode | Auto Read (Fast, Medium, Slow), Timed, Continuous |
| Measurement Reading Prompts | Reading, Stable, Locked |
| Measurement Temp. Compensation | ATC, MTC |
| Input pH Electrode | BNC (Q9) |
| Input Temp. Probe | 4 pin aviation connectors |
| Output USB | PC |
| Output RS 232 | Printer |
| Backlight | Yes |
| Auto Shutdown | 1 min to 60 min, off |
| IP Rating | IP54 |
| Date and Time | Yes |
| Data Storage | 500 results each |
| GLP Features | Yes |
| Power | AC Adapter, 100 V to 240 V AC input, DC 9 V output |
| Temperature Range | 23 ºF to 230 ºF (-5 ºC to 110 ºC) |
| Temperature Resolution | 0.1 |
| Temperature Accuracy | 32.36 ºF (± 0.2 ºC) |
| Dimensions | 9.52 in x 7.67 in x 2.67 in (24.2 cm × 19.5 cm × 6.8 cm) |
| Dimensions (Carton) | 14.57 in x 12.60 in x 8.66 in (37 cm × 32 cm × 22 cm) |
| Weight | 31.74 oz (900 g) |
| Weight (Gross) | 5.51 lb (2.5 kg) |
