Features
- Two display modes: digital value mode and spectrum mode
- Large memory function: 100 x 100 measured results (100 testing points, 100 data can be stored in each testing points), 100 spectrograms (each testing point can store one spectrogram)
- Spectrogram can display in real time
- Histogram can be made according to the preset alarm line
Technical Specification
| Acceleration | 0.1 m2 /s to 392 m2 /s |
| Measuring range | |
| Velocity | 0.1 cm/s to 80 cm/s |
| Displacement | 0.1 mm to 1801 mm |
| Acceleration | 10 Hz to 200 Hz |
| Frequency Range | |
| Velocity | 10 Hz to 200 Hz |
| Displacement | 10 Hz to 200 Hz |
| Accuracy | ±5% |
| Temperature | 32 oF to 104 oF (0 oC to 40 oC) |
| Humidity | <=80% RH |
| Power | Li battery (continuous working 20 hours without backlight) |
| Dimension | 6.73 in x 3.09 in x 1.10 in (171 mm x 78.5 mm x 28 mm) |
| Weight | 0.50 lb (230 g) |
