Features
- Color High contrast LCD touchscreen
- Calibration management
- Method management
- Data management
- Multi-reading feature
- Timed-read
- Continuous read
- Automatic or Manual temperature compensation
- Data Storage 1000 sets
- Support for USB or RS-232 communication
- Reset feature
- IP54 waterproof
- 1-6 points calibration
- including DIN, NIST, USA, MERK, JIS, GB
- Support for pH standard group customization
- Automatic electrode diagnosis with pH slope and offset display
Technical Specifications
| PH Range | -2.000 to 20.000 pH |
| PH Resolution | 0.1, 0.01, 0.001pH |
| PH Accuracy | ±0.002 pH |
| PH Calibration Points | Up to 6 |
| PH Standard Customization | Yes |
| PH Calibration Reminder | Yes |
| PH Standard Recognition | NIST, GB, DIN, USA, MERK, JIS buffers |
| PH Slope Limit | Yes |
| MV/ORP Range | -2000.00 mV to 2000.00 mV |
| MV/ORP Resolution | 0.1 mV, 0.01 mV |
| MV/ORP Accuracy | ±0.1 mV or ±0.03 % |
| MV/ORP EH ORP Mode | Yes |
| ORP Calibration Points | 1 custom point (relative mV) |
| Data Storage | 1000 Groups |
| GLP Features | Yes |
| Log Management | Yes |
| pH Electrode | BNC (Q9) |
| USB | USB 2.0 flash memory device, PC |
| RS 232 | printer, scanner, auto-sampler |
| Backlight | Yes |
| Auto Shutdown | 1 min to 60 min, off |
| IP Rating | IP 54 |
| Date And Time | Yes |
| Measurement Reading Mode | Auto Read (Fast, Medium, Slow), Timed, Continuous |
| Measurement Reading Prompts | Reading, Stable, Locked |
| Power | AC Adapter, 100 V to 240 V AC input, DC 24 V output |
| Temp. Probe | 4-pin aviation connector |
| Temperature Range | -14 °F to 275 °F (-10 °C to 135 °C) |
| Temperature Resolution | 33.8 °F (0.1 °C) |
| Temperature Accuracy | ±33.8 °F (±0.1 °C) |
| Measurement Temperature Compensation | ATC, MTC |
| Dimension | 8.66 in x 7.67 in x 2.67 in (220 mm × 195 mm × 68 mm) |
| Weight | 2.09 lb. (950 g) |
