Features
- Color High contrast LCD touchscreen, 4.3 in (109.2 mm)
- Multi-reading feature allows auto-reading, timed-reading and continuous-read.
- Automatic/Manual temperature compensation ensures accurate results
- Auto-hold feature senses and locks the measurement endpoint
- Data capacity of up to 500 sets for each parameter (GLP-compliant)
- Support for USB communication
- Auto-power off feature effectively extends the battery service life
- Reset feature automatically resumes all settings back to default options
- IP 65 waterproof
- 1 point to 3 points calibration with Standard Recognition
- Settable parameters
- Temperature compensation type (none, linear, pure water)
Technical Specifications
| Conductivity Range | 0.000 μS per cm to 3000 mS per cm |
| Conductivity Resolution | 0.001 μS per cm minimum, various with range selection |
| Conductivity Accuracy | ± 0.5 % FS |
| Conductivity Calibration Points | Up to 5 points |
| Conductivity Standard Recognition | 146.5 μS per cm, 1408 μS per cm, 12.85 mS per cm, 111.3 mS per cm |
| Resistivity Range | 5.00 cm to 100.00 cm |
| Resistivity Resolution | 0.01 cm minimum |
| Resistivity Accuracy | ± 0.5 % FS |
| TDS Range | 0.000 ppm to 1000 ppm |
| TDS Resolution | 0.001 ppm minimum, changed with range |
| TDS Accuracy | ± 0.5 % FS |
| Salinity Type | NaCl % |
| Salinity Range | 0.00 % to 8.00 % |
| Salinity Resolution | 0.01 % |
| Salinity Accuracy | ± 0.1 % |
| Measurement Reading Mode | Auto Read (Fast, Medium, Slow), Timed, Continuous |
| Measurement Reading Prompts | Reading, Stable, Locked |
| Measurement Temp. Compensation | ATC, MTC |
| Data management Data Storage | 1000 Groups |
| Data management GLP Features | Yes |
| Data management Log Management | Yes |
| Inputs Temp. Probe | 6 pin Mini DIN |
| Inputs Conductivity Probe | 8 pin Mini DIN |
| Power | AC Adapter, 100 V to 240 V AC input, DC 24 V output |
| Conductivity Reference Temperature | 41 °F (5 ºC), 50 °F (10 ºC), 59 °F (15 ºC), 64.4 °F (18 ºC), 68 °F (20 ºC), 77 °F (25 ºC) |
| Temperature Range | 23 °F to 266 °F (-5 ºC to 130 ºC) |
| Temperature Resolution | 32.18 °F (0.1 ºC) |
| Temperature Accuracy | 32.18 °F (± 0.1 ºC) |
| Dimensions | 11 in x 11 in x 5.1 in (28 cm × 28 cm × 13 cm) |
| Weight | 5.51 lb (2.5 kg) |
