Features
- High precision, strong pressure resistance
- High synchronous sampling frequency
- Extremely low power consumption
- Expansion performance can be customized according to requirements
Technical Specification
| Pressure Rating | 0 in (0 m) to 7874.01 in (200 m) (Customizable) |
| Conductivity range | 0 mS/cm to 200 mS/cm (Customizable) |
| Resolution | 1 uS/cm |
| Accuracy | EC: 2%; P: ±0.5%; Temp: 32.9 °F (±0.5 ℃) |
| Temperature range | 32 °F to 140 °F (0.0 ºC to 60.0 ºC) |
| Temperature compensation | Automatic |
| power consumption | <3 W |
| Data communication | Rs 485 (MODBUS-RTU) |
| Power supply | DC 12 V |
| Signal Output | RS 485 MODBUS RTU |
| Shell material | Stainless Steel + POM |
| Thread | NPT 3/4 |
| Cable length | 393.70 in (10 m) or customization |
| Protection grade | IP 68 |
