| Parameters |
EC or Temp. (Resistivity or TDS or Sal.) |
| Conductivity |
| Range |
0.000 μS/cm to 2000 mS/cm |
| Resolution |
0.001 μS/cm minimum, various with range selection |
| Accuracy |
± 0.5% FS |
| Calibration Points |
Up to 5 |
| Calibration Reminder |
Yes |
| Standard Recognition |
10 μS/cm, 84 μS/cm, 500 μS/cm, 1413 μS/cm, 12.88 mS/cm |
| Resistivity |
| Range |
5.00 Ω·cm to 100.00 M Ω·cm |
| Resolution |
0.01 Ω·cm minimum |
| Accuracy |
± 0.5% FS |
| TDS |
| Range |
0 ppt to 1000 ppt |
| Resolution |
0.001 ppm minimum, changed with range |
| Accuracy |
± 0.5% FS |
| Salinity |
| Type |
NaCl% |
| Range |
0% to 8% |
| Resolution |
0.01% |
| Accuracy |
±0.1% |
| Temperature |
| Unit |
℃, °F |
| Resolution |
0.1 |
| Accuracy |
±0.1 |
| Measurement |
| Reading Mode |
Auto Read (Fast, Medium, Slow), Timed, Continuous |
| Reading Prompts |
Reading, Stable, Locked |
| Temp. Compensation |
ATC, MTC |
| Data Management |
| Data Storage |
1000 Groups |
| GLP Features |
Yes |
| Log Management |
Yes |
| Inputs Conductivity with Temp. Probe |
5-pin aviation connector |
| Outputs |
| USB |
USB 2.0 flash memory device, PC |
| RS 232 |
printer |
| Display Options |
| Backlight |
Yes |
| Auto Shutdown |
1 min to 60 min, off |
| IP Rating |
IP 54 |
| Date and Time |
Yes |
| Power |
AC Adapter, 100 V to 240 V AC input, DC 9 V output |
| Temperature Range |
14 °F to 275 °F (-10 ℃ to 135 ℃) |
| Conductivity Reference Temperature |
41 ℉, 50 ℉, 59 ℉, 64.4 ℉, 68 ℉, and 77 ℉ (5 ℃, 10 ℃, 15 ℃, 18 ℃, 20 ℃, and 25 ℃) |
| Dimensions |
8.66 in × 7.68 in × 2.68 in (220 mm × 195 mm × 68 mm) |
| Weight |
2.09 lb (950 g) |
