Features
- 7″ high-res capacitive touch screen
- Microprocessor with intelligent features, USB output
- Smart electrode status display for accuracy
- Stores 1000 test data sets, Excel-compatible
- Advanced conductivity measurement technology
- Measures 0.5 μS/cm to 200 mS/cm accurately
- Switches between conductivity, TDS, salinity, resistivity
- Auto recognizes 8 conductivity standard solutions
Technical Specifications
| Cond. Measuring Range | Conductivity:0.00 μS/cm to 20.00 μS/cm,20.0 μS/cm to 200.0 μS/cm200 μS/cm to 2000 μS/cm,2.00 mS/cm to 20.00 mS/cm20.0 mS/cm to 200.0 mS/cm,200 mS/cm to 2000 mS/cm (K=10)TDS: 0 g/L to 100 g/LSalinity: 0 ppt to 100 pptResistivity: 0 MΩ·cm to 100 MΩ·cm |
| Cond. Resolution | 0.01 μS/cm or 0.1 μS/cm or 1 μS/cm; 0.01 mS/cm or 0.1 mS/cm |
| Cond. Accuracy | Electrode: ±0.5% FS, Meter: ±0.8% FS |
| Cond. Electrode Constant | 0.1 cm-1 or 0.5 cm-1 or 1 cm-1 or 5 cm-1 or 10 cm-1 or 50 cm-1 or 100 cm-1 |
| Display | 7-in coloured capacitive touch screen |
| Data Storage | 1000 sets |
| Power | 12 V / 1 A |
| Output | USB |
| Ambient Humidity | ≤85% |
| IP Grade | IP 54 |
| Cond. Reference Temp. | 77 °F, 68 °F, and 64.4 °F (25 ℃, 20 ℃, and 18 ℃) |
| Temp. Range | 18 °F to 230 °F (-10 ℃ to 110 ℃) |
| Temp. Resolution | 32.18 °F (0.1 ℃) |
| Temp. Accuracy | 41 °F to 140 °F (5 ℃ to 60 ℃)±32.72 °F (±0.4 ℃) Others: ±1.44 °F (±0.8 ℃) |
| Cond. Temp. Compensation Range | 32 °F to 122 °F (0 ℃ to 50 ℃), auto |
| Ambient Temp. | 59 °F to 86 °F (15 ℃ to 30 ℃) |
| Dimensions | 8.46 in × 6.69 in × 1.45 in (215 mm × 170 mm × 37 mm) |
| Net Weight | 1.32 lb. (600 g) |
