Features
- Multi parameter conductivity meter contains the TDS, salinity and resistivity measurement modes
- 1 to 5 points calibration with automatic calibration solution recognition
- Selectable cell constant 0.1 or 1 or 10, normalization temperature 68°F or 77°F (20°C or 25°C)
- TDS conversion factor, seawater and practical salinity measurement modes
- Linear or pure water compensation improves the measurement accuracy
- Automatic Temperature Compensation ensures accurate reading
Technical Specifications
| Conductivity Range | 0 μS per cm to 20.00 μS per cm, 200.0 μS per cm, 2000 μS per cm, 20.00, 200.0 mS per cm |
| Conductivity Accuracy | ± 0.5 % F.S |
| TDS Range | 0 ppt to 100 ppt (Max. 200 ppt, depending on factor setting) |
| TDS Accuracy | ± 1% F.S |
| Salinity Range | 0 ppt to 10 ppt (Max. 80 ppt) |
| Salinity Accuracy | ± 1 % F.S |
| Resistivity Range | 0 MΩ to 100MΩ |
| Resistivity Accuracy | ± 1 % F.S |
| Cell Constant | K=0.1, 1, 10 or User defined |
| Memory | Stores up to 500 data sets, USB Communication Interface |
| Power Requirements | DC 5 V or 400 mA power adapter |
| Calibration Points | 1 point to 5 points |
| Temperature Compensation | 32 °F to 212 °F (0 °C to 100 °C), Manual or Automatic |
| Temperature Coefficient | 32 °F to 50 °F (0.0 °C to 10 °C) |
| Normalization Temperature | 68 °F or 77 °F (20 °C or 25 °C) |
| Dimensions(mm) | 8.27 in × 7.40 in × 2.36 in (210mm x 188mm x 60mm) |
| Weight(kg) | 3.30 lb (1.5kg) |
