Features
- 1-to-3-point automatic calibration
- Universal electrode holder
- Graphical navigation system
- Self-diagnostic display mode
- Standard lab sin 211 glass rechargeable pH electrode
- Long life reference system
- Crash resistance glass film
- Wide mV range of ±2000 mV for versatile measurements
- Extensive conductivity ranges from 0 mS/cm to 200.0 mS/cm
- Broad TDS range spanning from 0.1 mg/l to 1 g/l to 100 g/l
Technical Specifications
| mV Range | ±2000 mV |
| Conductivity Range | 0 mS/cm to 200.0 mS/cm |
| TDS Range | 0.1 mg/l to 1 g/l to 100 g/l (0.00022 lb to 220 lb) |
| Salinity Range | 0 ppt to 100 ppt |
| Temperature Range | 32 °F to 212 °F (0 ℃ to 100 ℃) |
| mV Accuracy | 1 mV |
| Conductivity Accuracy | ±1%F. S |
| Temperature Accuracy | 0.9 °F (0.5 ℃) |
| pH Range | 0 pH to 14.00 pH |
| pH Resolution | 0.1 pH /0.01 pH |
| pH Accuracy | ±0.01 pH ±1 digit |
| Temp. Compensation | 32 °F to 212 °F (0 ℃ to 100 ℃) automatic or manual |
| Calibration Points | 1 point to 3 points |
| Calibration Solutions | USA/INST/CN Version |
| mV Range | ±2000 mV |
| mV Resolution | 1 mV |
| mV Accuracy | ±0.1%F. S ±1 digit |
| Conductivity Range | 0 mS/cm to 200.0 mS/cm |
| Conductivity Resolution | 0.1/1 μs, 0.01/0.1 ms |
| Conductivity Accuracy | ±1%F. S ±1 digit |
| Electrode Constant | 0.1/1.0/10.0 cm⁻¹ |
| Temp. Compensation | 32 °F to 122 °F (0 ℃ to 50 ℃), automatic or manual |
| Criterion Temperature | 59 °F to 86 °F (15 ℃ to 30 ℃) |
| Temp Compensation Coefficient | 0% to 10.00% per ℃ |
| Calibration | 1 point to 4 points automatic |
| Calibration Standard | USA/CH |
| TDS Range | 0.00022 lb to 220 (0.1 mg/l to 100 g/l) |
| TDS Coefficient | 0.10 to 1.00 |
| Salinity Range | 0 ppt to 100 ppt |
| Resistivity Range | NO |
| Temperature Range | 32 °F to 212 °F 0 (0 ℃) to 100.0 ℃) |
| Temperature Resolution | 0.18 °F (0.1 ℃) |
| Temperature Accuracy | ±0.9 °F (±0.5 ℃) ±1 digit |
| Display | TFT color display |
| IP Rating | IP 54 water and dust resistant |
| Electrode | pH: labSen211, Cond: 1301T-F |
| Other | Power: DC 9 V |
| Exterior Dimension | 7.87 in x 8.66 in x 3.94 in (200 mm x 220 mm x 100 mm) |
| Net Weight | 2.09 lb (0.95 kg) |
