Features
- The conductor structure has a nominal resistance of 1.00/ m ±5%
- It employs an LCD number display for reading measurements
- Power is supplied by an internal 6F22 type 9-volt battery with intermittent power supply capability.
- Designed to meet Riot level IAIIAT3 specifications
- It can function effectively in environments with a relative humidity of up to 85%
- Features a semi-secret structure with compact dimensions, fitting easily in the palm of your hand
- Weighs just 1.10 lb (0.5 kg) ensuring portability and ease of use
- Top of Form
Technical Specifications
| Conductivity Range | 0 pS/m to 19999 pS/m |
| Resolution | 1 pS/m |
| Accuracy | ±1 pS/m |
| Main Purpose | Aviation Kerosene, Compressor Oil, Lubricating Oil |
| Conductivity Unit | PS/m (Equivalent to CU – American Conductivity Unit) |
| Structure | Semi-secret Structure |
| Reading Method | LCD Number Display |
| Power Supply | Internal 6F22 Type 9 Volt Battery (Intermittent Power Supply) |
| Riot Level | Designed by IAIIAT3 |
| Use Environment | Temperature: 32 °F to 104 °F (0 °C to 40 °C) |
| Conductive Test Probe Can Work at Temperatures -40 °F to +392 °F (-40 °C to +200 °C) | |
| Relative Humidity: ≤85% | |
| Applicability | Suitable for Field or Oil-based Laboratory Use in Civilian or Airport Fuel Gas Stations |
| Dimensions | Host: φ3.94 in × 1.38 in (φ100 mm × 35 mm) |
| Electric: φ0.55 in × 5.51 in (φ14 mm × 140 mm) | |
| Weight | 1.1 lb (0.5 kg) |
