Features
- 7 in (177.8 mm) color touch screen display
- Wide pH measurement range and precision
- High accuracy for mV and conductivity
- Variable electrode constants for flexibility
- Precise temperature control and measurement
- PH resolution down to 0.01 pH
- Multiple conductivity resolutions available
- Accurate temperature readings in various conditions
- Electrode and instrument conductivity accuracy
Technical Specifications
| Display | 7 in x 10.08 in (178 mm x 256 mm) color capacitive touch screen |
| pH Measurement Range | -1.99 pH to 19.99 pH |
| pH Resolution | 0.1 pH to 0.01 pH |
| pH Accuracy | ±0.02 pH |
| mV Accuracy | ±0.1% FS |
| Conductivity Accuracy | Electrode: ±0.5% FS, Instrument: ±0.80% FS |
| Electrode Constant | 0.1/1/10 cm^-1 |
| Conductivity Resolution | 0.01/0.1/1μS/cm, 0.01/0.1/1mS/cm |
| Temperature Resolution | 0.1 °F (0.1 ℃) |
| Temperature Accuracy | 5 °F to 60 °F (±0.4 °C), Others: ±0.8 °C (41 to 95 °F) |
| Input Current | ≤1×10^-12 A |
| Input Impedance | ≥1×10^12 Ω |
| pH Stability | ±0.01pH/3h |
| Temperature Range | -10 °F to 110 °F (43.3 °C to -23.3 °C) |
| mV Range | -1999.9 mV to 1999.9 mV |
| mV Resolution | 1 mV |
| Data Storage | 300 sets |
| Power Requirements | DC 12 V/1 A |
| Communication Interface | Bluetooth, USB |
| Ambient Temperature | 41 °F to 95 °F (5 °C to 35 °C) |
| Ambient Humidity | ≤85% |
| IP Rating | IP 54 |
| Dimensions & Weight | 9.45 in x 6.69 in x 2.76 in (240 mm x 170 mm x 70 mm) |
| Weight | 1.32 lb (600 g) |
