Features
- Multi-reading feature
- Automatic / manual temperature compensation
- Auto-hold feature
- Data Storage 50 sets for each parameter
- 1 point calibration with standard recognition
- Cell constant is settable
Technical Specifications
| Parameters | Conductivity/TDS/ °C/°F |
| Cond Range | 0.00 μS/cm to 100 mS/cm |
| TDS Range | 0 g/L to 100 g/L |
| Temp Range | 23 °F to 230 °F (-5.00 °C to 110 °C) |
| EC Resolution | 0.01 μS/cm minimum, various with range selection |
| Reference Temperature | 77 °F (25 °C) |
| Calibration Points | Up to 1 |
| Standard Recognition | 84 μS/cm, 1413 μS/cm, 12.88 mS/cm |
| Tds Resolution | 0.01 mg/L minimum, various with range selection |
| Cond Accuracy | +1.0% (FS) |
| TDS Accuracy | + 1.0% (FS) |
| Temp Accuracy | ± 32.36 °F (± 0.2°C) + 1 bit |
| Temp compensation | Manual / Auto 32 °F to 104 °F (0.0 °C to 40.0 °C) |
| Temp resolution | 32.18 °F (0.1 °C) |
| Temp accuracy | ±32.36 °F (±0.1 °C) |
| Display | LCD, dual parameter |
| Power | AC (220 V ±22 V, 50 Hz + 1Hz |
| Reading Mode | Auto Read, Continuous |
| Reading Prompts | Reading, Stable, Locked |
| Temp Compensation | ATC, MTC |
| Data Storage | 50 results each |
| Conductivity with Temp Probe | 5 – pin aviation connector |
| Backlight | Yes |
| Auto Shutdown | 300 sec, 600 sec, 1200 sec, 1800 sec, 3600 sec |
| IP Rating | IP54 |
| Power | AC Adapter, 100 V AC to 240 V AC input, DC 9V output |
| Dimensions | 9.52 in x 7.67 in x 2.67 in (242 mm × 195 mm × 68 mm) |
| Weight | 1.98 lb. (900 g) |
