Features
- Sea water or high salinity water or various water supply or industrial water treatment
- Signal output RS-485 (ModbusRTU protocol), 4 mA to 20 mA current output
- Convenient connection to third party devices such as PLCs, DCS, industrial control computers, general controllers, paperless recording instruments, or touch screens
- Immersion installation with 3 or 4 NPT for easy installation in pipelines and tanks
- IP68 protection level
Technical Specifications
| Measuring Principle | Induction Electrode Method |
| Protection Class | IP68 |
| Output | RS 485(Modbus RTU), 4 mA to 20 mA |
| Shell Material | 316L |
| Installation Method | Input Type Installation,3 per 4NPT |
| Consumption | 0.2 W, 12 V |
| Power Supply | 12 V DC to 24 V DC |
| Accuracy | ± 1.5 % ± 32.54 °F (0.3 ℃) |
| Storage Temperature | 23 ℉ to 149 ℉ (-5 ℃ to 65 ℃) |
| Working Conditions | 32 ℉ to 104 ℉ (0 ℃ to 60 ℃), ≤ 0.6 MPa |
