Overview
This calibration TDS salinity Meter has conductivity accuracy ±0.5% FS, range of 0 vs./cm to 2000 mS/cm), and resolution of (0.001 μS/cm).
Technical Specifications
| Conductivity | |
| Range | 0 μS/cm to 2000 mS/cm |
| Resolution | 0.001 μS/cm minimum, various with range selection |
| Accuracy | ±0.5% FS |
| Reference Temperature | 5, 10, 15, 18, 20, 25 ºC |
| Calibration Points | Up to 5 |
| Calibration Reminder | Yes |
| Standard Recognition | 10 μS/cm, 84 μS/cm, 500 μS/cm, 1413 μS/cm, 12.88 mS/cm;146.5μS/cm, 1408μS/cm, 12.85mS/cm, 111.3mS/cm |
| Resistivity | |
| Range | 5.00 Ω·cm to 100.0 MΩ·cm |
| Resolution | 0.01 Ω·cm minimum |
| Accuracy | ±0.5% FS |
| TDS | |
| Range | 0 ppm to 1000 ppt |
| Resolution | 0.001 ppm minimum, changed with range |
| Accuracy | ±0.5% FS |
| Salinity | |
| Type | NaCl |
| Range | 0.0 ppt to 80.0 ppt |
| Resolution | 0.1 ppt |
| Accuracy | ±1 ppt |
| Temperature | |
| Range | 14 ºF to 275 ºF (-10 ºC to 135 ºC) |
| Unit | ºC, ºF |
| Resolution | 0.1 |
| Accuracy | ±0.18 °F (±0.1 ºC) |
| Measurement | |
| Reading Mode | Auto Read (Fast, Medium, Slow), Timed, Continuous |
| Reading Prompts | Reading, Stable, Locked |
| Temp. Compensation | ATC, MTC |
| Data Management | |
| Data Storage | 1000 Groups |
| GLP Features | Yes |
| Log Management | Yes |
| Inputs | |
| Conductivity With Temp. Probe | 5-pin aviation connector |
| Outputs | |
| USB | USB 2.0 flash memory device, PC, scanner |
| RS 232 | Printer, auto-sampler |
| Display Options | |
| Backlight | Yes |
| Auto Shutdown | 1 min to 60 min, off |
| IP Rating | IP54 |
| Date And Time | Yes |
| General | |
| Power | AC Adapter, 100 V to 240 V AC input, DC 24 V output |
| Dimensions | 8.66 in x 7.67 in x 2.67 in (220 mm x 195 mm x 68 mm) |
| Weight | 2.09 lb. (950 g) |
