Features
- pH Measurement with Calcium Hydroxide Electrode
- Temperature Measurement
- High pH Range
- Precision pH Measurement
- Suitable for Alkaline Solutions
- Easy Calibration
- Automatic Temperature Compensation (ATC)
- Replaceable Calcium Hydroxide Electrode
- Data Logging
- Data Storage
Technical Specification
| pH range | 0 pH to 14 pH |
| pH zero point | 7.00 ± 0.25 |
| Hydrofluoric acid concentration | ≤4000 ppm |
| Temperature range | 32 °F to 212 °F (0 °C to 100 °C) |
| Pressure resistance | 0 PSI to 87 PSI (0 kpa to 600 kpa) |
| Temperature sensor | CS 1543 C: None |
| Membrane resistance | <800 MΩ |
| Reference system | Ag/Agcl |
| Liquid interface | porous ceramic |
| Double salt bridge system | Yes |
| Electrolyte solution | KCL |
| Connection thread | PG 13.5 |
| Cable length | 196.8 in (5000 mm) |
| Cable connector | Pin, BNC |
| Waterproof grade | IP 68 |
| Housing material | glass |
| Monitor Controller Test | pH probe/pH electrode |
| Function 1 | 4 mA to 20 mA Online pH Meter pH/ORP |
| Function 2 | Controller for Industrial Process |
| Function 3 | Water Quality PH monitoring system |
| Function 4 | Industrial rs 485 online water orp pH sensor |
| orp transmitter | orp sensor |
