Features
- 7″ high-res LCD
- Multi-reading: auto, timed, continuous
- Auto/Manual temp compensation
- Auto-hold locks endpoint
- Data Storage: 500 sets (GLP)
- USB/RS-232 support
- Reset to factory defaults
- IP54 waterproof
- 1 point to 3 points calibration, Standard Recognition
- Settable parameters: cell constant, temp comp coefficient, TDS factor
- Temp comp type: none, linear, pure water
Technical Specifications
| Conductivity Range | 0.000 μS/cm to 1000 mS/cm |
| Resolution | 0.001 μS/cm Minimum, various with range selection |
| Accuracy | ±1.0% FS |
| Reference Temperature | 68 °F, 77 °F (20 °C, 25 °C) |
| Calibration Points | Up to 3 |
| Standard Recognition | 84 μS/cm, 1413 μS/cm, 12.88 mS/cm |
| Resistivity Range | 5.00 Ω·cm to 20.00 MΩ·cm |
| Resolution | 0.01 Ω·cm Minimum |
| Accuracy | ±1.0% FS |
| TDS Range | 0.00 ppm to 300 ppt |
| Resolution | 0.01 ppm Minimum, Various with range selection |
| Accuracy | ±1.0% FS |
| Salinity Range | 0.00% to 8.00% |
| Resolution | 0.01% |
| Accuracy | ±0.2% |
| Temperature Range | 23.0 °F to 230 °F (-5.0 °C to 110 °C) |
| Unit | °C, °F |
| Resolution | 0.1 |
| Accuracy | 32.36 °F (±0.2 °C) |
| Measurement Reading Mode | Auto Read (Fast, Medium, Slow), Timed, Continuous |
| Reading Prompts | Reading, Stable, Locked |
| Temp. Compensation | ATC, MTC |
| Data Management Data Storage | 500 results each |
| GLP Features | Yes |
| Inputs Conductivity with Temp. Probe | 5-pin aviation connector |
| Outputs USB | PC |
| RS 232 | Printer |
| Display OptionsBacklight | Yes |
| Auto Shutdown | 1 min to 60 min, off |
| IP Rating | IP 54 |
| Date and Time | Yes |
| General Power | AC Adapter, 100 V to 240 V AC input, DC 9 V output |
| Dimensions | 9.52 in × 7.67 in × 2.67 in (242 mm × 195 mm × 68 mm) |
| Weight | 1.98 lb (900 g) |
