| Parameters |
EC / Temp. (Resistivity / TDS / Sal.) |
| Conductivity Range |
0.000 μS/cm to 3000 mS/cm |
| Resolution |
0.001 μS/cm minimum, various with range selection |
| Accuracy |
±0.5% FS |
| Calibration Points |
Up to 5 |
| Standard Recognition |
146.5 μS/cm, 1408 μS/cm, 12.85 mS/cm, 111.3 mS/cm |
| Resistivity Range |
5.00 Ω·cm to 100.00 MΩ·cm |
| Resolution |
0.01 Ω·cm minimum |
| Accuracy |
±0.5% FS |
| TDS Range |
0.000 mg/L to 1000 g/L |
| Resolution |
0.001 ppm minimum, changed with range |
| Accuracy |
±0.5% FS |
| Salinity Type |
NaCl% |
| Range |
0.00% to 8.00% |
| Resolution |
0.01% |
| Accuracy |
±0.1% |
| Temperature Unit |
℃ |
| Resolution |
0.1 |
| Accuracy |
±0.1 |
| Measurement Reading Mode |
Auto Read (Fast, Medium, Slow), Timed, Continuous |
| Reading Prompts |
Reading, Stable, Locked |
| Temp. Compensation |
ATC, MTC |
| Data management |
| Data Storage |
1000 Groups |
| GLP Features |
Yes |
| Log Management |
Yes |
| Inputs Temp. Probe |
6-pin Mini-DIN |
| Conductivity Probe |
8-pin Mini-DIN |
| Outputs USB, RS 232 |
USB 2.0 flash memory device, printer, PC |
| Display options Backlight |
Yes |
| Auto Shutdown |
1 min to 60 min, off |
| IP Rating |
IP 54 |
| Date and Time |
Yes |
| Power |
AC Adapter, 100 V to 240 V AC input, DC 24 V output |
| Reference Temperature |
41 ℉, 50 ℉, 59 ℉, 64.4 ℉, 68 ℉, and 77 °F (5 ℃, 10 ℃, 15 ℃, 18 ℃, 20 ℃, and 25 ℃) |
| Temperature Range |
23 ℉ to 266 ℉ (-5 ℃ to 130 ℃) |
| Dimensions |
11.02 in × 11.02 in × 5.11 in (280 mm × 280 mm × 130 mm) |
| Weight |
5.51 lb. (2.5 kg) |
