Overview
This Benchtop Conductivity Salinity Temperature meter has pH range of 0.00 pH to14.00 pH, mV resolution of 0.1 mV, and pH accuracy of ±0.01 pH.
Features
- Automatic or manual temperature compensation (pH)
- Automatic buffer recognition of US and NIST buffer sets (pH)
- Dedicated pushbuttons for key operations
- Reliable and Repeatable Results
- 1012 Ω input impedance (pH)
- 2 Points calibration (pH)
- 2-Wire conductivity (conductivity, salinity, TDS)
- 1 Point per range calibration (conductivity, salinity, TDS)
- K = 0.1, 1.0 and 10.0 (conductivity, salinity, TDS)
Technical Specifications
| Range | |
| PH | 0.00 pH to 14.00 pH |
| MV | -1999.9 mV to 1999.9 mV |
| Temperature | 32 °F to 212 °F (0.0 °C to 100.0 °C) |
| Resolution | |
| PH | 0.01 pH |
| MV | 0.1 mV |
| Temperature | 32.18 °F (0. 1 °C) |
| Accuracy | |
| PH | ±0.01 pH |
| MV | ±0.4 mV (-1500.0 to 1500.0); ±1 mv (-1999.9 to 1500.0 and 1500.0 to 1999.9) |
| Temperature | ±0.2 °F (±0.2 °C) |
| PH Buffer Recognition | US (pH 4.01, 7.00, 10.01) or NIST (pH 4.00, 6.86, 9.18), user selectable |
| PH Calibration | 1, 2, or 3 points calibrations |
| PH Electrode Offset Recognition | ±1.50 pH |
| PH Electrode Slope Recognition | ±30% at pH 4.00, 4.01, 9.18 or 10.01. |
| Input Impedance | >1013 Ω |
| Power | 6 V x 1.5 V AAA batteries or 115 V or 230 V AC adapter |
| Operating Ambient Conditions | From 32 °F to 122 °F (0 °C to 50 °C), at 90% RH |
| Case | IP-54 waterproof |
| Buffer Temp. Range | 32 °F to 140 °F (0.0 °C to 60.0 °C) |
| PH Temp Compensation | Auto or manual 32 °F to 212 °F (0.0 °C to 100.0 °C.) |
| Dimensions | 5.90 in × 7.99 in × 2.83 in (150 mm x 203 mm x 72 mm) |
| Weight | 1.11 lb. (504 gm) |
