Overview
Hospitaity Enviro Tech All-in-one portable digital pH meter pen and pocket tester is equipped with a standard pH electrode (Circular glass bulb) used to measure the pH of non viscous, non high temperature liquids, e.g., tap water, drinking water, rainwater, etc. This product is equipped with a flat surface pH electrode used to measure the pH of semisolid substances, e.g., fruits, bread, creams, etc. It is equipped with a long reach pH electrode used to measure the liquids in the test tube. The tester is equipped with a standard BNC connector, which can use any pH electrode with BNC plug.
Features
- High accuracy at 0.1 pH
- Designed for acid testing applications
- pH ranges from 0.0 pH to 14.0 pH
- Calibration at 2 points
- Equipped with a 6-pin connector
- Manual hold function for convenience
Technical Specifications
| pH Range | -2.00 pH to 16.00 pH
-2.000 pH to 20.000 pH -2.000 pH to 20.000 pH |
| pH Accuracy | ± 0.01 pH
± 0.002 pH ± 0.002 pH |
| Resolution | 0.01 pH, 0.1pH, 0.01 pH, 0.001 pH, Selectable
0.1 pH, 0.01 pH, 0.001 pH, Selectable |
| Calibration Points | 2 points 1 point to 5 points
1 point to 5 points |
| Calibration Solutions | USA (4.01 pH or 7.00 pH or 10.01 pH)
USA (1.68 pH or 4.01 pH or 7.00 pH or 10.01 pH or 12.45 pH), NIST (1.68 pH or 4.01 pH or 6.86 pH or 9.18 pH or 12.45 pH), DIN (1.09 pH or 4.65 pH or 6.79 pH or 9.23 pH or 12.75 pH) or User defined USA (1.68 pH or 4.01 pH or 7.00 pH or 10.01 pH or 12.45 pH), NIST (1.68 pH or 4.01 pH or 6.86 pH or 9.18 pH or 12.45 pH), DIN (1.09 pH or 4.65 pH or 6.79 pH or 9.23 pH or 12.75 pH) or User defined |
| mV Range | -1999 mV to 1999 mV -1999.9 mV to 1999.9 mV
-1999.9 mV to 1999.9 mV |
| mV Accuracy | ± 1 mV ±0.2 mV
± 0.2 mV |
| Resolution | 1 mV 0.1 mV, 1 mV, Selectable
0.1 mV, 1 mV, Selectable |
| Calibration Points | 1 point (Only for Relative mV mode) |
| Ion Concentration Range | 0.001 ppm to 19999 ppm, mg per L, mol per L (Refer to the range of ISE) |
| Ion Concentration Accuracy | ± 0.5 % F.S (Monovalent), ± 1 % F.S (Divalent) |
| Calibration Points | 2 points to 5 points (0.001 ppm, 0.01 ppm, 0.1 ppm, 1, 10 ppm, 100 ppm, 1000 ppm, 10000 ppm, mg per L, mol per L) |
| Hold Function | Manual |
| Memory | Stores up to 50 data sets Stores up to 500 data sets
Stores up to 500 data sets |
| Output | USB Communication Interface USB Communication Interface |
| Connector | BNC |
| Power Requirements | 1 V per 800 mA to 9 V per 800 mA battery 3×1.5 V “AA” batteries (Standard) or DC 5 V power adapter (Optional) 3 V to 1.5 V “AA” batteries (Standard) or |
| Temperature Compensation | 32 °F to 212 °F (0 °C to 100 °C) Manual or Automatic 32 °F to 212 °F (0 °C to 100°C) Manual or Automatic
32 °F to 212 °F (0 °C to 100 °C) Manual or Automatic |
| Temperature Range | 32 °F to 212 °F (0 °C to 100 °C) 32 °F to 221 °F (0 °C to 105 °C) |
| Temperature Accuracy | ± 1.8 °F (± 1 °C) ± 0.9 °F (± 0.5 °C) |
| Resolution | ± 1.8 °F (± 1 °C) |
| Dimensions | 7.28 in x 3.47 in x 1.26 in (18.5 cm x 8.8 cm x 3.2 cm) 6.69 in x 3.35 in x 1.18 in (17 cm x 8.5 cm x 3 cm) |
| Net Weight | 10.58 oz (300 g) |
| Grows Weight | 4.40 lb (2 kg) |
