Features
- Insulation resistance range 15TΩ @ 15 kv.
- Short circuit current can be adjusted, maximum 5mA (Can be ordered as high as 10mA, short circuit current products).
- Automatic display polarization index (PI) induced electric absorption test values than (DAR), and can test the leakage current and capacitance.
- Anti-jamming performance is superior, the interference current reaches 2 mA, still ensure accuracy of test instruments.
- 2 methods for power: use of lithium ion batteries, battery life can be up to 4 hours (10000V @ 100MΩ).
- Insulation resistance simulation column.
- Digital filtering functions, external influence deviation display value causing mitigation point using filter function.
- Perfect protection function, and the spare fuse prompt functions.
Technical Specifications
| AC Power | 220V±10%, 50/60 HZ, 20 VA |
| Battery | 16.8V Lithium ion rechargeable battery |
| Battery Life | 10000V@100M, 4 hours |
| Test Voltage Accuracy | The nominal value 100% to 110% |
| Voltage Measurement Accuracy | 5% + 3V |
| Current Test Range | 10mA |
| Current Measure Precision | 5% + 0.2nA |
| Short-Circuit Current | 5mA |
| Capacitance Test Range | 20uF |
| Capacitance Testing Accuracy | 15% + 0.03uF |
| High-Voltage Insulation Resistance Tester | With 5 range: 500V, 1000V, 2500V, 5000V, 10000V, 15000V |
| Test Resistance | Up to 15TΩ |
| Manual Voltage Regulation Function | Yes |
| Size (L x W x H) | 14.57 in x 10.63 in x 6.69 in (37 cm x 27 cm x 17 cm) |
| Weight | (7.94 lbs) 3.6 kg |
