Features
- High-sensitivity ultrasonic flaw detection for cracks & weld inspection
- Frequency range: 0.5–15 MHz
- Adjustable gain: 0–120 dB
- Vertical linearity error ≤ 3%
- Supports single, dual, and thru modes
- Material velocity range: 1000–15000 m/s
- Compact, portable, and user-friendly design
Technical Specifications
| Title | Parameter |
| Measuring Range | 0 to 10000 mm (0 to 393.7 in) |
| Measurement Mode | Single, Dual, or Thru |
| Vertical Linearity Error | ≤ 3% |
| Reject | 0 to 80% |
| Horizontal Linearity Error | ≤ 0.1% |
| Pulse Displacement | -20 to +3400 μs |
| Sensitivity Leavings | ≥ 62 dB |
| Zero | 0.0 to 99.99 μs |
| Dynamic Range | ≥ 32 dB |
| Port Type | BNC (Q9) |
| Resolving Power | ≥ 36 dB |
| Frequency Range | 0.5 to 15 MHz |
| Gain | 0 to 120 dB |
| Material Velocity | 1000 to 15000 m/s (3280.84 to 49212.6 ft/s) |
| Operating Temperature | -4 °F to 122 °F (-20 °C to 50 °C) |
| Weight | 2.2 lb (1.0 kg, with battery) |
| Size (H × W × D) | 9.45 in × 6.14 in × 1.89 in (240 mm × 156 mm × 48 mm) |
