Overview
Hospitality Enviro Tech’s High precision clamp liquid flow meter is a speed-type flow meter based on torque balance. It is widely used in petroleum, chemical industry, metallurgy, water supply, and papermaking. It is an ideal meter for flow measurement and energy saving.
Features
- Simple structure and convenient reading
- Lightweight, high precision, and good repeatability
- Responsive installation and maintenance
- Intelligent LCD meter head
- Strong anti-interference
- High-quality material selection and multiple tests
- One fine-turning turbine
- A variety of precisions
- Energy saving
- High efficiency one key reset
Technical Specification
| Power Supply | 24 V DC or 3.6 battery |
| Accuracy | 0.5% |
| Measuring Pipe size | -30 °F to 160 °F (-34.4 °C to 71.1 °C) |
| Output | 4 mA to 20 mA or OTC pulse, Relay signal |
| Temperature | -4 °F to 266 °F (-20 °C to 130 °C) |
| Medium | Water, Liquid, and Oil |
| Pressure | 232.06 PSI, 362.6 PSI, 580.15 PSI, 913.7 PSI, 1450.38 PSI, 2320.6 PSI, 3626 PSI (1.6 Mpa, 2.5 Mpa, 4.0 Mpa, 6.3 Mpa, 10 Mpa, 16 Mpa, 25 Mpa) |
| Size | DN 4 to DN 200 |
