Features
- High bandwidth options up to 2GHz for detailed signal analysis
- 12-bit or 10-bit ADC ensures exceptional vertical resolution accuracy
- Fast 10GSa/s real-time sampling rate for precise waveform capture
- 750,000 wfms/s waveform refresh rate minimizes missed signals
- Large 12.1-inch screen for clear visualization and intuitive operation
- Ideal for automotive, communication, and power measurement applications
Technical Specifications
| Type | Digital Storage Oscilloscope |
| Structure | Desktop |
| Application | Voltage, Frequency, Time, Phase, Power, and Displacement Measurements |
| Sampling Mode | Real-time Sampling |
| Bandwidth | 350 MHz to 2 GHz |
| Vertical Resolution (ADC) | 12-bit (H12) or 10-bit (H10) |
| Sampling Rate | 5 GSa/s or 10 GSa/s |
| Memory Depth | 250 Mpts/CH or 500 Mpts/CH |
| Waveform Capture Rate | 750,000 wfms/s |
| Screen Size | 12.1 in display |
| Operating Temperature | 32 °F to 104 °F (0 °C to 40 °C) |
| Product Weight | 17.64 lb (8 kg) |
| Package Dimensions | 19.69 in x 11.81 in x 7.87 in (50 cm x 30 cm x 20 cm) |
