High-Current True RMS Clamp Meter with Peak Hold Function – Hospitality Enviro Tech

High-Current True RMS Clamp Meter with Peak Hold Function measures up to 2000A, 1000V, and 999.9KW with 6000-count display and wide frequency range.

SKU: HETCM-144 Category:

Overview

Hospitality Enviro Tech DC or AC clamp meter can be used in most industrial and commercial applications where nonlinear loads distort current or voltage waveform. Peak hold function. In rush current measurement 2000 A true RMS. It could be used in family, school, lab and other circumstance, where high current measurement is required.



Technical Specification

Display Type Digital Only
Current 2000 A
Voltage 1000 V
Clamp Jaw Opening 2 in (52 mm)
Digital Display Count 6000
Resistance 60 MΩ
Capacitance 10 mF
Power Supply 9 V battery
Electronic Frequency 100 KHz
Temperature 1832 °F (1000 °C)
Harmonic Distortion 99.9%
Active Power 999.9 KW
Dimensions 12.13 in x 3.82 in x 1.85 in (308 mm x 97 mm x 47 mm)
Weight 1.61 lb (732 g)
