Features
- Dual-frequency measurement: Two speed bands let you tailor readings—great for general machinery or high-frequency bearing checks.
- Easy to read: “Full display” LCD doesn’t specify backlighting—fine for daylight, less so in low light.
- Flexible power input: Runs on six AAA batteries or a 9 V adapter—great for field ops, but don’t expect USB charging.
- Field ready, simple: Compact with efficient power consumption (15 mA) removes battery anxiety, though no battery-level indicator is mentioned.
- Missing depth: No mention of accuracy, measurement ranges, data output, or environmental ratings—ask for the full datasheet if anything important hinges on precision or durability.
Technical Specifications
| Specification | Details |
| Measurement Modes | Acceleration, Velocity, Displacement |
| Sensor Type | Piezoelectric (shear-type) accelerometer |
| Dual Frequency Ranges | Low: 20 Hz–1 kHz; High: 1 kHz–10 kHz |
| Display | LCD (full display, no backlight indicated) |
| Power Supply & Current | 6 × AAA (1.5 V) or DC 9 V adapter; ~15 mA consumption |
| Auto Power-Off | Yes — unspecified timeout |
| Other Features | Simple full display, dual frequency switch, compact portable design |
